BOJACK Terminal Fuse 60A Marine Rated Battery Fuse (MRBF) 58V DC Max IP66 Waterproof for the Circuit Protection of Automobiles RVs Cranes Ships Charging Piles 60Amp(Pack of 2)

Terminal Fuse 60A Marine Rated Battery Fuse (MRBF) 58V DC Max IP66 Waterproof Application: Full range circuit protection for automotive and marine applications.The breaking capacity meets the requirements of conventional vehicle batteries and 12V, 24V and 42V electrical networks.10,000 AIC at 14V DC satisfies ABYC requirements for DC Main circuit protection on large battery banks. Compact, high-amp fuse appropriate for DC Main, inverters, windlass and bow thruster circuit protection.Designed to provide high current protection in tight space constraints.Ignition protected when used with MRBF Terminal Fuse Blocks.Isolated stud design uses standard M8 hardware and permits stacking of terminals. Suitable for main and auxiliary circuit protection such as alternator outputs, starter motor inputs and accessory circuits.Alleviates having to make up a short wire to connect to a standard fuse block to the battery. Specification: Rated Current: 60A Rated Voltage: 58VDC Ingress Protection: IP66 Ignition Protected: Per SAEJ1117 Interrupt Capacity: 10000A @ 14VDC, 5000A @ 32VDC, 2000A @ 58VDC Maximum Torque: 12Nm (1224Kgf-cm) (106 in-lbs) Material: body, insulating material ceramic; housing & cover, UL-rated 94V0 thermoplastic; fuse, copper alloy (nickel plated), ring terminals, tin plated Features: high load capacity, ignition protection, visible fuse, security, easy to install Notice: DO NOT mount fuse directly onto battery post. Fuses should be mounted on the MRBF terminal fuse block. Package Included: 2 X MRBF Battery Terminal Fuse 60A

• Product: MRBF Fuse 2pcs (Fuse Block NOT Included), perfectly compatible with M8 stud fuse box - single or dual terminal fuse block
• Max Voltage Rating: 58V; Amperage Rating: 60A; Fuse Holder Stud Size: M8 (5/16"); Fuse Holder Mounting Hole: M10 (3/8")
• High Safety Performance: with ignition protection, safe for installation aboard gasoline powered boats; with heat detection function, automatic trip when current overload, reset after a short time; IP66 waterproof, protected against powerful water jets
• Function: The fuse responds sensitively and fuses accurately. When the circuit is abnormal and damages the battery pack and the main circuit, the fuse blows , thereby protecting the battery and circuitry from damage.
• Application: Widely used in new energy vehicles, RVs, cruise ships, cranes, batteries, charging piles and other DC main power supplies, inverters, windlasses and bow thrusters. 【USE WARNING: Do not mount fuses directly on battery terminals. Must use with Terminal Fuse Blocks PN 5191 or PN 2151.】
